EAN:
SKU: PSBM6 Wireless Bluetooth Car Battery Tester APP Bluetooth 4.0 Battery Monitoring iOS and Android mobile phone solar system / car charging and startup test
Test Battery internal resistance voltage CCA Health and Charging Battery Capacity and Battery Load Multifunction Battery Analyzer Lead Acid and Lithium Battery Tester Auto / Heavy Truck / Ship / Motorcycle / SUV / yacht / scooter / split / machine / Bicycle Battery Diagnostics General Factory Direct
technical parameter
Auto Parts: Mr.Abbas
Bluetooth version: 4.2
Input voltage: DC 6V ~ 20V
Voltage accuracy (9V~16V):±0.03V
Operating current: 1.5 mA
Reverse connection protection: built-in
Short-circuit protection: built-in
Waterproof grade: IP67
Main control chip: APM32F103VCT6
Operating temperature: 0- + 50℃
Storage temperature: -20- + 70℃
LCD: 128x64
Test lead: 100cm / 40in
major function:
1.Receives notifications of battery conditions in Bluetooth range.
2.Checks vehicle cranking system automatically while engine is starting.
3.Checks charging system (alternator)
4.Lists the time of each driving.
5.Alerts mobile phone if detects abnormal data.
6.Short-circuit and reverse connection protection.
7.Data stored in battery monitor up to 35 days if out of sync.
8.Automatic synchronization when in Bluetooth range.
9.Compatible with all 12V vehicle batteries.
10.Shows historical data graphically.
11.Engine starting detection automatically.
12.Free app for iOS and Android.
13.Support multi-battery management
14. Exclusive private account, data will not be lost
15.Car location seeking function via google map.
16. Trip record with map and route.
17.Works with all 12V batteries./Wireless (Bluetooth 4.0) in10 meter./ Software included for Android and iPhone./All Apps for Android and iPhone are designed by ourselves,download for free via Internet.
18. Support: German, English, French, Italian, Spanish, Dutch, Polish, and Finnish
19. Product certification: CE FCC ROHS UKCA
measuring range
DIN/IEC: 20-1400
JIS: 26A17-245H52
CCA/BCI/CA/MCA/EN/SAE: 20-2000
GB: 30-220Ah
Product application:
12V batteries for testing various 12V wet (liquid rich), valve-controlled lead or maintenance-free (MF), seal maintenance-free (SMF), absorption glass felt (AGM) and GEL, batteries (start [SLI], deep cycle and marine batteries). Lithium-ion battery, support the major battery standards JIS, SAE, EN, DIN and IEC.
Phone Support: All iOS and Android smartphones with Bluetooth 4.0 iOS support (iPhone 4S, 5,5C, 5S and newer models; iPad 2, iPad Air, iPad mini, iPad mini 2 and later)
Android: At least Android 4.3 (Bluetooth 4.0 phone)
Product size: 17X13.5X2.5cm
Package size: 18x14.2x3.0cm
Package weight: 650g
Quantity quantity: 40 pcs
From from China (OBD <3 KG):
Any purchase of 2 or more products to enjoy a 5% discount.
US, 7-12 working days for delivery.
The retail price of US Section 2-5 includes postage.
Area 6- $3 to the base retail price;
Zone 7- $5 more postage to the base retail price;
Zone 8- $7 more postage to the base retail price;
Area 9- $9 on base retail price.
factory outlet:
Support bulk order price negotiation and delivery methods.
Support e-commerce one generation hair.
