Coilovers Shocks Struts Kit for Mitsubishi Lancer 2008-2016 Suspension Lowering Kit 64556247
Application
For Mitsubishi Lancer(CX/CY) 2008-2016, except Lancer Evolution
For Mitsubishi Outlancer Sport(GA) 2011-2020
Features
Lower ride height between 1 and 3 inches, will not keep OE height
Independent Ride Height And Spring Tension Settings
Top Camber Plate Allows Camber Angle Adjustment
High Rigidity 55CrSi Steel Cold-bent Coil Springs
Anodized Shock Body With Anti-Corrosion Coating
CNC Billet Aluminum Parts/Hardware.
Specification
- Top mounts: pillow ball top mount with camber plate front, standard rubber top mount rear.
- Damping: No adjustable damper force
- Front Spring Rate: 9kg/mm (504 lbs/in).
- Rear Spring Rate: 6 kg/mm (336 in/lbs).
- Coilover overall length Front: 430-500 mm
- Coilover overall length Rear: 365-400 mm
- Adjustable Height: Yes lowering 1" to 3".
- Shock type: Twin tube.
- Spring Preload: 7-10 mm.
- Color: Gold.
Package included
- Complete coilovers for 2 front and 2 rear
- A pair of wrenches for height adjustment
Authority ID: MXR02FXSY
Notice: California Prop 65 Warning
