EAN:
SKU: PSBA101 12V Automotive Battery Tester 100-2000 CCA Load Tester Automotive Alternator Test Battery Analyzer Charging Start System Tester Truck / Ship / Motorcycle / SUV / Yacht Battery Diagnostic General cold start current detection Factory direct sales
technical parameter
System voltage: 12V
Input voltage range: 9V-15V
Power supply requirements: No built-in battery is required
Capacity: Cold start Ampere (CCA), DIN, EN, IEC and battery ratings
Main control chip: APM32F103VCT6
Operating temperature: -20- - + 60℃
Storage temperature: -20- + 70℃
product description
1. Battery voltage detection
2. Battery impedance test
3. Residual power test
4. Battery life
5. Cold start current detection
6. Color screen is 2.8 inches
7. Support for German, English, Spanish, French, Italian, Dutch, Portuguese, Polish, and Russian
Product certification: CE / FCC / ROHS / UKCA
Product characteristics
1.Simple and easy to use
2.Tests batteries on and off the vehicle
3.Accurate results in milliseconds
4.Battery life analysis
5.Analysis results: Good or Replace
6.Large easy to read LCD screen
7.Test results based on JIS, EN, DIN, SAE and IEC Standards
8.Quick test - inputs battery volume (AH), then shows battery status
9.Vehicle cranking system test - cranking time, voltage and status
10.Store the testing result and the print function
11.Vehicle charging system test—load voltage, unloaded voltage, ripple status, and charging system status
measuring range
CCA:100-2000
BCI:100-2000
CA :100-2000
MCA: 100-2000
JIS :26A17--245H52
DIN :100-1400
IEC: 100-1400
EN :100-2000
SAE :100-2000
GB :100-1400
About the project
1. Compact and compact design, with a faster scanning speed, and the test results are directly displayed. Even beginners can use this device to analyze any 12-volt battery. It shows you all the information about the battery: voltage, charging, starting power, and remaining battery life (ohm resistance level). And it does this quickly and accurately.
2. Wide test range (100-2000 CCA), more accurate than competitors. The test results are based on JIS, EN, DIN, SAE, CCA, BCI, GB, CA, MCA, and IEC standards.
3. Provide opportunities to check the charging status of the alternator and the starter. Vehicle charging system tests are also provided, including load voltage, no-load voltage, ripple status, and charging system status.
4.BA101 battery tester is well made, with a large LCD display with white backlight and adjustable contrast to directly display the test results. No internal battery, directly get power from the 12V battery.
5.It with a 3. 0 ft cable, made of very thick flexible insulators, is much safer than other insulators on the market. With 101 buttons on the BA4. Up / down button is used for the scroll menu. The "Enter" and "Exit" buttons are used to navigate backwards and enter the menu.
6.Leagend offers a 30-day money back guarantee, worry-free warranty and lifetime customer support. For technical support and any product problems, please contact us through the buyer-seller message to resolve the problem.
Support for multiple battery standards:
It can be tested by the AH and CCA values, but also applies to other testing criteria, such as BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB.
· If your battery standard is an AH standard, you can enter the AH value to test in the Quick Test menu.
· If your battery is CCA or other standard, enter CCA or other values to be tested in the Inside Battery or Outside Battery test menu.
keyword
Engine fault detector, OBD Bluetooth code card, battery tester, automotive diagnostic industrial reader and scanning tool, elm327OBD interface, motorcycle / yacht battery diagnostic instrument, motorcycle battery repair charger, quick removal of fault code, I / M status detection, onboard circuit detector, circuit analysis, intelligent diagnostic instrument, 12V general battery diagnostic instrument, multi-function battery diagnostic instrument, multimeter test meter, engine fault data flow code card, electrical tester and test lead, emission analyzer, fuel pressure tester, gas analyzer, ignition tester, laboratory oscilloscope, mechanical tester , Multimeter and analyzer, pressure and vacuum tester, software, thermometer, timing lamp, airbag scanning tool, and simulator
Motorcycle tire pressure sensor, Bluetooth tire pressure monitor, auto tire pressure monitor, tire abnormal alarm, air compressor and inflation, fender and splash cover, tire maintenance, tire cover, tire pressure gauge, tire pressure monitoring system, monitoring tire pressure sensor, tire pressure, tire repair tools, wheel accessories, tire accessories, tire and wheel repair, vehicle tire pressure digital meter, automobile, bus, trucks, tractors, bicycles, motorcycle tire pressure detection tools
Product size: 156 * 88 * 24mm
Packaging size: 200 * 130 * 43mm
Package weight: 370g
Quantity quantity: 40 pcs
From from China (OBD <3 KG):
Any purchase of 2 or more goods retail prices enjoy a 5% discount.
US, 7-12 working days for delivery.
The retail price of US Section 2-5 includes postage.
Area 6- $3 to the base retail price;
Zone 7- $5 more postage to the base retail price;
Zone 8- $7 more postage to the base retail price;
Area 9- $9 on base retail price.
Support for bulk order price negotiation and delivery method.
